Manufacturer: Savant

Model Number: WI3-SWS102

Series: Metropolitan Auxiliary Control

Condition: New-Open Box

Additional Notes:

The Savant WI3-SWS102 (snow white) and WI3-LAS102 (light almond) Auxiliary Control are a companion to the Savant Metropolitan
wireless dimmers, switches, and keypads. The Auxiliary Control is wired in such a way that allows for control of one load from multiple
locations such as in a 3-way configuration. There is no limit to the number of Auxiliary Controls that can be wired to one Savant
Metropolitan dimmer, keypad, or switch.
Unlike other Metropolitan devices, the Auxiliary Control cannot be connected to a wireless network. All control signals from the
Auxiliary Control are sent over a traveler wire back to a Savant Metropolitan style dimmer, switch, or keypad. The Metropolitan device
then outputs the appropriate voltage to the load.
IMPORTANT! Using this product in a manner that is not consistent with this document will void your warranty

Specifications
Environmental
Temperature 32° to 104° F (0° to 40° C)
Humidity 10% to 90% Relative Humidity (non-condensing)
Location Indoor Use Only
Dimensions
Height 4.13 in (10.49 cm) / Shipping 7.0 in (17.78 cm)
Width 2.38 in (6.05 cm) / Shipping 4.5 in (11.43 cm)
Depth 1.81 in (4.60 cm) / Shipping 3.0 in (7.62 cm)
Weight (Shipping) 0.60 lb (0.272 kg)
Recommended Back Box Depth Dimensions
All Metro Auxiliary Controls require a standard U.S. electrical back box
• Recommended – 3.5 in (8.89 cm) deep
• Minimum – 2.25 in (5.72 cm) deep
Power
120V AC on traveler wire (yellow)
Supported Load Types
Not Applicable
Regulatory
Safety and Emissions UL
RoHS Compliant
Minimum Supported Release
Savant® OS da Vinci® 7.2.1

What’s Included:

• Metropolitan Auxilary Control without faceplate
•  2 Mounting Screws   6/32 x 3/4 inch
• 3 Wire Nuts
• Quick reference guide

Dimensions (L x W x H): 4.5 x 3 x 7 in, Weight: 1 lbs

Shipping Info: Free shipping applies to items being delivered within the contiguous United States (lower 48). HI, AK, PR, and all other US Territories, and International locations will have shipping calculated during checkout.

Return Info: 30-Day Returns

Warranty Info: 90-Day Warranty
